母端排针 L496XX-XXXXX
双排直线型2.54 mm (0.100")

添加到我的收藏夹

添加到产品对比表

产品规格型号

类型: 母端
形状: 双排
其他特性: 直线型
螺距: 2.54 mm (0.100")

产品介绍

Part No: L495XX-XXXXX Mating:L496XX-XXXXX Packing:Tray Delivery time:7~15 Day UL:Yes ROHS Compliant Current Rating - 3.0AMP Contact Resistance - 30mΩ Max Withstand Voltage - 1000V AC/DC Insulation Resistance - 1000mΩ Operation Temperature - ﹣55℃ to +105℃ Contact Material - Brass Contact Plating - Au And Sn over Ni Fixing Material - Phosphor Bronze Fixing Plating - Sn over Ni Housing Material - PBT+30%GF(UL94V-0) Cover Material - PBT+30%GF(UL94V-0
